Charts in Adaptive Cards

You can visually represent data through charts in Adaptive Cards. You can use charts for performance dashboards, budget allocations, project management, customer insights, and more.

Donut chart

You can use the Chart.Donut element to add a donut chart in an Adaptive Card.

Card

Payload

{
  "type": "AdaptiveCard",
  "version": "1.5",
  "body": [
    {
      "type": "Chart.Donut",
      "data": [
        {
          "legend": "Pear",
          "value": 59
        },
        {
          "legend": "Banana",
          "value": 292
        },
        {
          "legend": "Apple",
          "value": 143
        },
        {
          "legend": "Peach",
          "value": 98
        },
        {
          "legend": "Kiwi",
          "value": 179
        },
        {
          "legend": "Grapefruit",
          "value": 50
        },
        {
          "legend": "Orange",
          "value": 212
        },
        {
          "legend": "Cantaloupe",
          "value": 68
        }
      ]
    }
  ]
}

Here are the properties of the Chart.Donut element:

Property	Required	Type	Description
type	✔️	String	Must be Chart.Donut.
colorSet		String	The name of the set of colors to use to render the chart.
data	✔️	Array of objects	The data to display in the chart.
fallback		Object or String	An alternate element to render if this type of element is unsupported or if the host application doesn't support all the capabilities specified in the requires property. Allowed values: Container, ActionSet, ColumnSet, Media, RichTextBlock, Table, TextBlock, FactSet, ImageSet, Image, Input.Text, Input.Date, Input.Time, Input.Number, Input.Toggle, Input.ChoiceSet, Input.Rating, Rating, CompoundButton, Icon, Chart.Donut, Chart.Pie, Chart.VerticalBar.Grouped, Chart.VerticalBar, Chart.HorizontalBar, Chart.HorizontalBar.Stacked, Chart.Line, Chart.Gauge, CodeBlock, drop
grid.area		String	The area of a Layout.AreaGrid layout in which an element must be displayed.
height		String	The height of the element. When set to stretch, the element uses the remaining vertical space in its container. Allowed values: auto, stretch Default value: auto
horizontalAlignment		String	Controls how the element must be horizontally aligned. Allowed values: Left, Center, Right
id		String	A unique identifier for the element or action.
isVisible		Boolean	Controls the visibility of the element. Default value: true
lang		String	The locale associated with the input element.
requires		Object	A list of capabilities the element requires the host application to support. If the host application doesn't support at least one of the listed capabilities, the element isn't rendered or its fallback is rendered, if provided. Allowed values: HostCapabilities
separator		Boolean	Controls whether a separator line must be displayed above the element to visually separate it from the previous element. No separator is displayed for the first element in a container, even if this property is set to true. Default value: false
spacing		String	Controls the amount of space between this element and the previous one. No space is added for the first element in a container. Allowed values: None, Small, Default, Medium, Large, ExtraLarge, Padding Default value: Default
targetWidth		String	Controls the card width for which the element must be displayed. If targetWidth isn't specified, the element is rendered at all card widths. Using targetWidth makes it possible to author responsive cards that adapt their layout to the available horizontal space. For more information, see Adaptive Card responsive layout. Allowed values: VeryNarrow, Narrow, Standard, Wide, atLeast:VeryNarrow, atMost:VeryNarrow, atLeast:Narrow, atMost:Narrow, atLeast:Standard, atMost:Standard, atLeast:Wide, atMost:Wide
title		String	The title of the chart.

Here are the properties of the data array:

Property	Required	Type	Description
color		String	The color to use for the data point. Allowed values: good, warning, attention, neutral, categoricalRed, categoricalPurple, categoricalLavender, categoricalBlue, categoricalLightBlue, categoricalTeal, categoricalGreen, categoricalLime, categoricalMarigold, sequential1, sequential2, sequential3, sequential4, sequential5, sequential6, sequential7, sequential8, divergingBlue, divergingLightBlue, divergingCyan, divergingTeal, divergingYellow, divergingPeach, divergingLightRed, divergingRed, divergingMaroon, divergingGray
legend		String	The legend of the chart.
value		Number	The value associated with the data point.

Gauge chart

You can use the Chart.Gauge element to add a gauge chart in an Adaptive Card.

Card

Payload

{
  "type": "AdaptiveCard",
  "version": "1.5",
  "body": [
    {
      "type": "TextBlock",
      "text": "Basic",
      "size": "extraLarge"
    },
    {
      "type": "Chart.Gauge",
      "value": 50,
      "segments": [
        {
          "legend": "Low risk",
          "size": 33,
          "color": "good"
        },
        {
          "legend": "Medium risk",
          "size": 34,
          "color": "warning"
        },
        {
          "legend": "High risk",
          "size": 33,
          "color": "attention"
        }
      ]
    },
    {
      "type": "TextBlock",
      "text": "Single value",
      "size": "extraLarge",
      "spacing": "large",
      "separator": true
    },
    {
      "type": "Chart.Gauge",
      "value": 35,
      "valueFormat": "fraction",
      "segments": [
        {
          "legend": "Used",
          "size": 35
        },
        {
          "legend": "Unused",
          "size": 65,
          "color": "neutral"
        }
      ]
    }
  ]
}

Here are the properties of the Chart.Gauge element:

Property	Required	Type	Description
type	✔️	String	Must be Chart.Gauge.
colorSet		String	The name of the set of colors to use to render the chart.
fallback		Object or String	An alternate element to render if this type of element is unsupported or if the host application doesn't support all the capabilities specified in the requires property. Allowed values: Container, ActionSet, ColumnSet, Media, RichTextBlock, Table, TextBlock, FactSet, ImageSet, Image, Input.Text, Input.Date, Input.Time, Input.Number, Input.Toggle, Input.ChoiceSet, Input.Rating, Rating, CompoundButton, Icon, Chart.Donut, Chart.Pie, Chart.VerticalBar.Grouped, Chart.VerticalBar, Chart.HorizontalBar, Chart.HorizontalBar.Stacked, Chart.Line, Chart.Gauge, CodeBlock, drop
grid.area		String	The area of a Layout.AreaGrid layout in which an element must be displayed.
height		String	The height of the element. When set to stretch, the element uses the remaining vertical space in its container. Allowed values: auto, stretch Default value: auto
horizontalAlignment		String	Controls how the element must be horizontally aligned. Allowed values: Left, Center, Right
id		String	A unique identifier for the input element.
isVisible		Boolean	Controls if the element is visible. Default value: true
lang		String	The locale associated with the input element.
max		Number	The maximum value of the gauge.
min		Number	The minimum value of the gauge.
requires		Object	A list of capabilities the element requires the host application to support. If the host application doesn't support at least one of the listed capabilities, the element isn't rendered or its fallback is rendered, if provided. Allowed values: HostCapabilities
segments		Array of objects	The segments to display in the gauge.
separator		Boolean	Controls whether a separator line must be displayed above the element to visually separate it from the previous element. No separator is displayed for the first element in a container, even if this property is set to true. Default value: false
showLegend		Boolean	Controls if the legend must be displayed. Default value: true
showMinMax		Boolean	Controls if the min or max values must be displayed. Default value: true
spacing		String	Controls the amount of space between this element and the previous one. No space is added for the first element in a container. Allowed values: None, Small, Default, Medium, Large, ExtraLarge, Padding Default value: Default
subLabel		String	The sub-label of the gauge.
targetWidth		String	Controls the card width for which the element must be displayed. If targetWidth isn't specified, the element is rendered at all card widths. Using targetWidth makes it possible to author responsive cards that adapt their layout to the available horizontal space. For more information, see Adaptive Card responsive layout. Allowed values: VeryNarrow, Narrow, Standard, Wide, atLeast:VeryNarrow, atMost:VeryNarrow, atLeast:Narrow, atMost:Narrow, atLeast:Standard, atMost:Standard, atLeast:Wide, atMost:Wide
title		String	The title of the chart.
value		Number	The value of the gauge. Default value: 0
valueFormat		String	The format used to display the gauge's value. Allowed values: Percentage, Fraction Default value: Percentage

Here are the properties of the segments array:

Property	Required	Type	Description
color		String	The color to use for the segment. Allowed values: good, warning, attention, neutral, categoricalRed, categoricalPurple, categoricalLavender, categoricalBlue, categoricalLightBlue, categoricalTeal, categoricalGreen, categoricalLime, categoricalMarigold, sequential1, sequential2, sequential3, sequential4, sequential5, sequential6, sequential7, sequential8, divergingBlue, divergingLightBlue, divergingCyan, divergingTeal, divergingYellow, divergingPeach, divergingLightRed, divergingRed, divergingMaroon, divergingGray
legend		String	The legend text associated with the segment.
value		Number	The size of the segment. Default value: 0

Grouped vertical bar chart

You can use the Chart.VerticalBar.Grouped element to add a grouped or a stacked vertical bar chart in an Adaptive Card.

Card

Payload

{
  "type": "AdaptiveCard",
  "version": "1.5",
  "body": [
    {
      "type": "TextBlock",
      "text": "Grouped",
      "size": "large",
      "separator": true,
      "spacing": "large"
    },
    {
      "type": "Chart.VerticalBar.Grouped",
      "title": "Sample",
      "xAxisTitle": "Days",
      "yAxisTitle": "Sales",
      "colorSet": "diverging",
      "data": [
        {
          "legend": "Outlook",
          "values": [
            {
              "x": "2023-05-01",
              "y": 24
            },
            {
              "x": "2023-05-02",
              "y": 27
            },
            {
              "x": "2023-05-03",
              "y": 18
            },
            {
              "x": "2023-05-04",
              "y": 30
            },
            {
              "x": "2023-05-05",
              "y": 20
            },
            {
              "x": "2023-05-06",
              "y": 35
            },
            {
              "x": "2023-05-07",
              "y": 40
            },
            {
              "x": "2023-05-08",
              "y": 45
            }
          ]
        },
        {
          "legend": "Teams",
          "values": [
            {
              "x": "2023-05-01",
              "y": 9
            },
            {
              "x": "2023-05-02",
              "y": 100
            },
            {
              "x": "2023-05-03",
              "y": 22
            },
            {
              "x": "2023-05-04",
              "y": 40
            },
            {
              "x": "2023-05-05",
              "y": 30
            },
            {
              "x": "2023-05-06",
              "y": 45
            },
            {
              "x": "2023-05-07",
              "y": 50
            },
            {
              "x": "2023-05-08",
              "y": 55
            }
          ]
        },
        {
          "legend": "Office",
          "values": [
            {
              "x": "2023-05-01",
              "y": 10
            },
            {
              "x": "2023-05-02",
              "y": 20
            },
            {
              "x": "2023-05-03",
              "y": 30
            },
            {
              "x": "2023-05-04",
              "y": 40
            },
            {
              "x": "2023-05-05",
              "y": 50
            },
            {
              "x": "2023-05-06",
              "y": 60
            },
            {
              "x": "2023-05-07",
              "y": 70
            },
            {
              "x": "2023-05-08",
              "y": 80
            }
          ]
        },
        {
          "legend": "Windows",
          "values": [
            {
              "x": "2023-05-01",
              "y": 10
            },
            {
              "x": "2023-05-02",
              "y": 20
            },
            {
              "x": "2023-05-03",
              "y": 30
            },
            {
              "x": "2023-05-04",
              "y": 40
            },
            {
              "x": "2023-05-05",
              "y": 50
            },
            {
              "x": "2023-05-06",
              "y": 60
            },
            {
              "x": "2023-05-07",
              "y": 70
            },
            {
              "x": "2023-05-08",
              "y": 80
            }
          ]
        }
      ]
    },
    {
      "type": "TextBlock",
      "text": "Stacked",
      "size": "large",
      "separator": true,
      "spacing": "large"
    },
    {
      "type": "Chart.VerticalBar.Grouped",
      "stacked": true,
      "title": "Sample",
      "xAxisTitle": "Days",
      "yAxisTitle": "Sales",
      "data": [
        {
          "legend": "Outlook",
          "values": [
            {
              "x": "2023-05-01",
              "y": 24
            },
            {
              "x": "2023-05-02",
              "y": 27
            },
            {
              "x": "2023-05-03",
              "y": 18
            },
            {
              "x": "2023-05-04",
              "y": 30
            },
            {
              "x": "2023-05-05",
              "y": 20
            },
            {
              "x": "2023-05-06",
              "y": 35
            },
            {
              "x": "2023-05-07",
              "y": 40
            },
            {
              "x": "2023-05-08",
              "y": 45
            }
          ]
        },
        {
          "legend": "Teams",
          "values": [
            {
              "x": "2023-05-01",
              "y": 9
            },
            {
              "x": "2023-05-02",
              "y": 100
            },
            {
              "x": "2023-05-03",
              "y": 22
            },
            {
              "x": "2023-05-04",
              "y": 40
            },
            {
              "x": "2023-05-05",
              "y": 30
            },
            {
              "x": "2023-05-06",
              "y": 45
            },
            {
              "x": "2023-05-07",
              "y": 50
            },
            {
              "x": "2023-05-08",
              "y": 55
            }
          ]
        },
        {
          "legend": "Office",
          "values": [
            {
              "x": "2023-05-01",
              "y": 10
            },
            {
              "x": "2023-05-02",
              "y": 20
            },
            {
              "x": "2023-05-03",
              "y": 30
            },
            {
              "x": "2023-05-04",
              "y": 40
            },
            {
              "x": "2023-05-05",
              "y": 50
            },
            {
              "x": "2023-05-06",
              "y": 60
            },
            {
              "x": "2023-05-07",
              "y": 70
            },
            {
              "x": "2023-05-08",
              "y": 80
            }
          ]
        },
        {
          "legend": "Windows",
          "values": [
            {
              "x": "2023-05-01",
              "y": 10
            },
            {
              "x": "2023-05-02",
              "y": 20
            },
            {
              "x": "2023-05-03",
              "y": 30
            },
            {
              "x": "2023-05-04",
              "y": 40
            },
            {
              "x": "2023-05-05",
              "y": 50
            },
            {
              "x": "2023-05-06",
              "y": 60
            },
            {
              "x": "2023-05-07",
              "y": 70
            },
            {
              "x": "2023-05-08",
              "y": 80
            }
          ]
        }
      ]
    }
  ]
}

Here are the properties of the Chart.VerticalBar.Grouped element:

Property	Required	Type	Description
type	✔️	String	Must be Chart.VerticalBar.Grouped.
color		String	The color to use for all data points. Allowed values: good, warning, attention, neutral, categoricalRed, categoricalPurple, categoricalLavender, categoricalBlue, categoricalLightBlue, categoricalTeal, categoricalGreen, categoricalLime, categoricalMarigold, sequential1, sequential2, sequential3, sequential4, sequential5, sequential6, sequential7, sequential8, divergingBlue, divergingLightBlue, divergingCyan, divergingTeal, divergingYellow, divergingPeach, divergingLightRed, divergingRed, divergingMaroon, divergingGray
colorSet		String	The name of the set of colors to use to render the chart.
data		Array of objects	The data points in the chart.
fallback		Object or String	An alternate element to render if this element is unsupported or if the host application doesn't support all the capabilities specified in the requires property. Allowed values: Container, ActionSet, ColumnSet, Media, RichTextBlock, Table, TextBlock, FactSet, ImageSet, Image, Input.Text, Input.Date, Input.Time, Input.Number, Input.Toggle, Input.ChoiceSet, Input.Rating, Rating, CompoundButton, Icon, Chart.Donut, Chart.Pie, Chart.VerticalBar.Grouped, Chart.VerticalBar, Chart.HorizontalBar, Chart.HorizontalBar.Stacked, Chart.Line, Chart.Gauge, CodeBlock, drop
grid.area		String	The area of a Layout.AreaGrid layout in which an element must be displayed.
height		String	Controls the height of the element. When set to stretch, the element uses the remaining vertical space in its container. Allowed values: auto, stretch Default value: auto
horizontalAlignment		String	Controls how the element must be horizontally aligned. Allowed values: Left, Center, Right
id		String	A unique identifier for the input element or action.
isVisible		Boolean	Controls if the element is visible. Default value: true
lang		String	The locale associated with the input element.
requires		Object	A list of capabilities the element requires the host application to support. If the host application doesn't support at least one of the listed capabilities, the element isn't rendered or its fallback is rendered, if provided. Supported value: HostCapabilities
separator		Boolean	Controls whether a separator line must be displayed above the element to visually separate it from the previous element. No separator is displayed for the first element in a container, even if this property is set to true. Default value: false
showBarValues		Boolean	Controls if the bar values must be displayed. Default value: false
spacing		String	Controls the amount of space between this element and the previous one. No space is added for the first element in a container. Allowed values: None, Small, Default, Medium, Large, ExtraLarge, Padding Default value: Default
targetWidth		String	Controls the card width for which the element must be displayed. If targetWidth isn't specified, the element is rendered at all card widths. Using targetWidth makes it possible to author responsive cards that adapt their layout to the available horizontal space. For more information, see Adaptive Card responsive layout. Allowed values: VeryNarrow, Narrow, Standard, Wide, atLeast:VeryNarrow, atMost:VeryNarrow, atLeast:Narrow, atMost:Narrow, atLeast:Standard, atMost:Standard, atLeast:Wide, atMost:Wide
title		String	The title of the chart.
xAxisTitle		String	The title of the x axis.
yAxisTitle		String	The title of the y axis.

Here are the properties of the data array:

Property	Required	Type	Description
color		String	The color to use for the data point. Allowed values: good, warning, attention, neutral, categoricalRed, categoricalPurple, categoricalLavender, categoricalBlue, categoricalLightBlue, categoricalTeal, categoricalGreen, categoricalLime, categoricalMarigold, sequential1, sequential2, sequential3, sequential4, sequential5, sequential6, sequential7, sequential8, divergingBlue, divergingLightBlue, divergingCyan, divergingTeal, divergingYellow, divergingPeach, divergingLightRed, divergingRed, divergingMaroon, divergingGray
legend		String	The legend of the chart.
values		Number	The data points in the series.

Here are the properties of values:

Property	Required	Type	Description
x		String	The x axis value of the data point.
y		Number	The y axis value of the data point.

Horizontal bar chart

You can use the Chart.HorizontalBar element to add a horizontal bar chart in an Adaptive Card.

Card

Payload

{
  "type": "AdaptiveCard",
  "version": "1.5",
  "body": [
    {
      "type": "TextBlock",
      "text": "Standard with displayMode = AbsoluteWithAxis",
      "size": "large"
    },
    {
      "type": "Chart.HorizontalBar",
      "title": "Sample",
      "xAxisTitle": "Days",
      "yAxisTitle": "Sales",
      "colorSet": "diverging",
      "data": [
        {
          "x": "Pear",
          "y": 59
        },
        {
          "x": "Banana",
          "y": 292
        },
        {
          "x": "Apple",
          "y": 143
        },
        {
          "x": "Peach",
          "y": 98
        },
        {
          "x": "Kiwi",
          "y": 179
        },
        {
          "x": "Grapefruit",
          "y": 20
        }
      ]
    },
    {
      "type": "TextBlock",
      "text": "Standard with displayMode = AbsoluteNoAxis",
      "size": "large",
      "spacing": "large",
      "separator": true
    },
    {
      "type": "Chart.HorizontalBar",
      "title": "Sample",
      "displayMode": "AbsoluteNoAxis",
      "data": [
        {
          "x": "Pear",
          "y": 59
        },
        {
          "x": "Banana",
          "y": 292
        },
        {
          "x": "Apple",
          "y": 143
        },
        {
          "x": "Peach",
          "y": 98
        },
        {
          "x": "Kiwi",
          "y": 179
        },
        {
          "x": "Grapefruit",
          "y": 20
        }
      ]
    },
    {
      "type": "TextBlock",
      "text": "Standard with displayMode = PartToWhole",
      "size": "large",
      "spacing": "large",
      "separator": true
    },
    {
      "type": "TextBlock",
      "text": "Learning - Have you defined your goal for today's Day of learning"
    },
    {
      "type": "Chart.HorizontalBar",
      "title": "Sample",
      "displayMode": "PartToWhole",
      "color": "categoricalPurple",
      "data": [
        {
          "x": "Yes, I have defined my day of learning goal",
          "y": 15
        },
        {
          "x": "No, I haven't yet had time to do it",
          "y": 24
        },
        {
          "x": "I am not interested in learning",
          "y": 2
        }
      ]
    }
  ]
}

Here are the properties of the Chart.HorizontalBar element:

Property	Required	Type	Description
type	✔️	String	Must be Chart.HorizontalBar.
color		String	The color to use for all data points. Allowed values: good, warning, attention, neutral, categoricalRed, categoricalPurple, categoricalLavender, categoricalBlue, categoricalLightBlue, categoricalTeal, categoricalGreen, categoricalLime, categoricalMarigold, sequential1, sequential2, sequential3, sequential4, sequential5, sequential6, sequential7, sequential8, divergingBlue, divergingLightBlue, divergingCyan, divergingTeal, divergingYellow, divergingPeach, divergingLightRed, divergingRed, divergingMaroon, divergingGray
colorSet		String	The name of the set of colors to use to render the chart.
data		Array of objects	The data points in the chart.
displayMode		String	Controls how the chart must be visually laid out. Allowed values: AbsoluteWithAxis,AbsoluteNoAxis,PartToWhole Default value: AbsoluteWithAxis
fallback		Object or String	An alternate element to render if this element is unsupported or if the host application doesn't support all the capabilities specified in the requires property. Allowed values: Container, ActionSet, ColumnSet, Media, RichTextBlock, Table, TextBlock, FactSet, ImageSet, Image, Input.Text, Input.Date, Input.Time, Input.Number, Input.Toggle, Input.ChoiceSet, Input.Rating, Rating, CompoundButton, Icon, Chart.Donut, Chart.Pie, Chart.VerticalBar.Grouped, Chart.VerticalBar, Chart.HorizontalBar, Chart.HorizontalBar.Stacked, Chart.Line, Chart.Gauge, CodeBlock, drop
grid.area		String	The area of a Layout.AreaGrid layout in which an element must be displayed.
height		String	Controls the height of the element. When set to stretch, the element uses the remaining vertical space in its container. Allowed values: auto, stretch Default value: auto
horizontalAlignment		String	Controls how the element must be horizontally aligned. Allowed values: Left, Center, Right
id		String	A unique identifier for the input element or action.
isVisible		Boolean	Controls if the element is visible. Default value: true
lang		String	The locale associated with the input element.
requires		Object	A list of capabilities the element requires the host application to support. If the host application doesn't support at least one of the listed capabilities, the element isn't rendered or its fallback is rendered, if provided. Supported value: HostCapabilities
separator		Boolean	Controls whether a separator line must be displayed above the element to visually separate it from the previous element. No separator is displayed for the first element in a container, even if this property is set to true. Default value: false
spacing		String	Controls the amount of space between this element and the previous one. No space is added for the first element in a container. Allowed values: None, Small, Default, Medium, Large, ExtraLarge, Padding Default value: Default
targetWidth		String	Controls the card width for which the element must be displayed. If targetWidth isn't specified, the element is rendered at all card widths. Using targetWidth makes it possible to author responsive cards that adapt their layout to the available horizontal space. For more information, see Adaptive Card responsive layout. Allowed values: VeryNarrow, Narrow, Standard, Wide, atLeast:VeryNarrow, atMost:VeryNarrow, atLeast:Narrow, atMost:Narrow, atLeast:Standard, atMost:Standard, atLeast:Wide, atMost:Wide
title		String	The title of the chart.
xAxisTitle		String	The title of the x axis.
yAxisTitle		String	The title of the y axis.

Here are the properties of the data array:

Property	Required	Type	Description
color		String	The color to use for the data point. Allowed values: good, warning, attention, neutral, categoricalRed, categoricalPurple, categoricalLavender, categoricalBlue, categoricalLightBlue, categoricalTeal, categoricalGreen, categoricalLime, categoricalMarigold, sequential1, sequential2, sequential3, sequential4, sequential5, sequential6, sequential7, sequential8, divergingBlue, divergingLightBlue, divergingCyan, divergingTeal, divergingYellow, divergingPeach, divergingLightRed, divergingRed, divergingMaroon, divergingGray
x		String	The x axis value of the data point.
y		Number	The y axis value of the data point.

Line chart

You can use the Chart.Line element to add a line chart in an Adaptive Card.

Card

Payload

{
  "type": "AdaptiveCard",
  "version": "1.5",
  "body": [
    {
      "type": "Chart.Line",
      "title": "Sample",
      "xAxisTitle": "Days",
      "yAxisTitle": "Sales",
      "colorSet": "categorical",
      "data": [
        {
          "legend": "Outlook",
          "values": [
            {
              "x": "2023-05-01",
              "y": 99
            },
            {
              "x": "2023-05-02",
              "y": 6
            },
            {
              "x": "2023-05-03",
              "y": 63
            },
            {
              "x": "2023-05-04",
              "y": 64
            },
            {
              "x": "2023-05-05",
              "y": 63
            },
            {
              "x": "2023-05-06",
              "y": 78
            }
          ]
        },
        {
          "legend": "Teams",
          "values": [
            {
              "x": "2023-05-01",
              "y": 12
            },
            {
              "x": "2023-05-02",
              "y": 82
            },
            {
              "x": "2023-05-03",
              "y": 12
            },
            {
              "x": "2023-05-04",
              "y": 33
            },
            {
              "x": "2023-05-05",
              "y": 1
            },
            {
              "x": "2023-05-06",
              "y": 80
            }
          ]
        },
        {
          "legend": "Office",
          "values": [
            {
              "x": "2023-05-01",
              "y": 66
            },
            {
              "x": "2023-05-02",
              "y": 93
            },
            {
              "x": "2023-05-03",
              "y": 65
            },
            {
              "x": "2023-05-04",
              "y": 13
            },
            {
              "x": "2023-05-05",
              "y": 90
            },
            {
              "x": "2023-05-06",
              "y": 48
            }
          ]
        },
        {
          "legend": "Windows",
          "values": [
            {
              "x": "2023-05-01",
              "y": 9
            },
            {
              "x": "2023-05-02",
              "y": 19
            },
            {
              "x": "2023-05-03",
              "y": 0
            },
            {
              "x": "2023-05-04",
              "y": 61
            },
            {
              "x": "2023-05-05",
              "y": 21
            },
            {
              "x": "2023-05-06",
              "y": 72
            }
          ]
        },
        {
          "legend": "Exchange",
          "values": [
            {
              "x": "2023-05-01",
              "y": 35
            },
            {
              "x": "2023-05-02",
              "y": 11
            },
            {
              "x": "2023-05-03",
              "y": 91
            },
            {
              "x": "2023-05-04",
              "y": 97
            },
            {
              "x": "2023-05-05",
              "y": 97
            },
            {
              "x": "2023-05-06",
              "y": 45
            }
          ]
        },
        {
          "legend": "SharePoint",
          "values": [
            {
              "x": "2023-05-01",
              "y": 26
            },
            {
              "x": "2023-05-02",
              "y": 99
            },
            {
              "x": "2023-05-03",
              "y": 16
            },
            {
              "x": "2023-05-04",
              "y": 26
            },
            {
              "x": "2023-05-05",
              "y": 91
            },
            {
              "x": "2023-05-06",
              "y": 22
            }
          ]
        },
        {
          "legend": "Copilot",
          "values": [
            {
              "x": "2023-05-01",
              "y": 96
            },
            {
              "x": "2023-05-02",
              "y": 37
            },
            {
              "x": "2023-05-03",
              "y": 27
            },
            {
              "x": "2023-05-04",
              "y": 5
            },
            {
              "x": "2023-05-05",
              "y": 45
            },
            {
              "x": "2023-05-06",
              "y": 59
            }
          ]
        }
      ]
    }
  ]
}

Here are the properties of the Chart.Line element:

Property	Required	Type	Description
type	✔️	String	Must be Chart.Line.
color		String	The color to use for all data points. Allowed values: good, warning, attention, neutral, categoricalRed, categoricalPurple, categoricalLavender, categoricalBlue, categoricalLightBlue, categoricalTeal, categoricalGreen, categoricalLime, categoricalMarigold, sequential1, sequential2, sequential3, sequential4, sequential5, sequential6, sequential7, sequential8, divergingBlue, divergingLightBlue, divergingCyan, divergingTeal, divergingYellow, divergingPeach, divergingLightRed, divergingRed, divergingMaroon, divergingGray
colorSet		String	The name of the set of colors to use to render the chart.
data		Array of objects	The data points in the chart.
fallback		Object or String	An alternate element to render if this element is unsupported or if the host application doesn't support all the capabilities specified in the requires property. Allowed values: Container, ActionSet, ColumnSet, Media, RichTextBlock, Table, TextBlock, FactSet, ImageSet, Image, Input.Text, Input.Date, Input.Time, Input.Number, Input.Toggle, Input.ChoiceSet, Input.Rating, Rating, CompoundButton, Icon, Chart.Donut, Chart.Pie, Chart.VerticalBar.Grouped, Chart.VerticalBar, Chart.HorizontalBar, Chart.HorizontalBar.Stacked, Chart.Line, Chart.Gauge, CodeBlock, drop
grid.area		String	The area of a Layout.AreaGrid layout in which an element must be displayed.
height		String	Controls the height of the element. When set to stretch, the element uses the remaining vertical space in its container. Allowed values: auto, stretch Default value: auto
horizontalAlignment		String	Controls how the element must be horizontally aligned. Allowed values: Left, Center, Right
id		String	A unique identifier for the input element or action.
isVisible		Boolean	Controls if the element is visible. Default value: true
lang		String	The locale associated with the input element.
requires		Object	A list of capabilities the element requires the host application to support. If the host application doesn't support at least one of the listed capabilities, the element isn't rendered or its fallback is rendered, if provided. Supported value: HostCapabilities
separator		Boolean	Controls whether a separator line must be displayed above the element to visually separate it from the previous element. No separator is displayed for the first element in a container, even if this property is set to true. Default value: false
spacing		String	Controls the amount of space between this element and the previous one. No space is added for the first element in a container. Allowed values: None, Small, Default, Medium, Large, ExtraLarge, Padding Default value: Default
targetWidth		String	Controls the card width for which the element must be displayed. If targetWidth isn't specified, the element is rendered at all card widths. Using targetWidth makes it possible to author responsive cards that adapt their layout to the available horizontal space. For more information, see Adaptive Card responsive layout. Allowed values: VeryNarrow, Narrow, Standard, Wide, atLeast:VeryNarrow, atMost:VeryNarrow, atLeast:Narrow, atMost:Narrow, atLeast:Standard, atMost:Standard, atLeast:Wide, atMost:Wide
title		String	The title of the chart.
xAxisTitle		String	The title of the x axis.
yAxisTitle		String	The title of the y axis.

Here are the properties of the data array:

Property	Required	Type	Description
color		String	The color to use for the data point. Allowed values: good, warning, attention, neutral, categoricalRed, categoricalPurple, categoricalLavender, categoricalBlue, categoricalLightBlue, categoricalTeal, categoricalGreen, categoricalLime, categoricalMarigold, sequential1, sequential2, sequential3, sequential4, sequential5, sequential6, sequential7, sequential8, divergingBlue, divergingLightBlue, divergingCyan, divergingTeal, divergingYellow, divergingPeach, divergingLightRed, divergingRed, divergingMaroon, divergingGray
legend		String	The legend of the chart.
values		Array of objects	The data points in the series.

Here are the properties of values:

Property	Required	Type	Description
x		One of number or string	The x axis value of the data point.
y		Number	The y axis value of the data point.

Pie chart

You can use the Chart.Pie element to add a pie chart in an Adaptive Card.

Card

Payload

{
  "type": "AdaptiveCard",
  "version": "1.5",
  "body": [
    {
      "type": "Chart.Pie",
      "colorSet": "categorical",
      "data": [
        {
          "legend": "Pear",
          "value": 59
        },
        {
          "legend": "Banana",
          "value": 292
        },
        {
          "legend": "Apple",
          "value": 143
        },
        {
          "legend": "Peach",
          "value": 98
        },
        {
          "legend": "Kiwi",
          "value": 179
        },
        {
          "legend": "Grapefruit",
          "value": 50
        },
        {
          "legend": "Orange",
          "value": 212
        },
        {
          "legend": "Cantaloupe",
          "value": 68
        }
      ]
    }
  ]
}

Here are the properties of the Chart.Pie element:

Property	Required	Type	Description
type	✔️	String	Must be Chart.Pie.
colorSet		String	The name of the set of colors to use to render the chart.
data		Array of objects	The data to display in the chart.
fallback		Object or String	An alternate element to render if this element is unsupported or if the host application doesn't support all the capabilities specified in the requires property. Allowed values: Container, ActionSet, ColumnSet, Media, RichTextBlock, Table, TextBlock, FactSet, ImageSet, Image, Input.Text, Input.Date, Input.Time, Input.Number, Input.Toggle, Input.ChoiceSet, Input.Rating, Rating, CompoundButton, Icon, Chart.Donut, Chart.Pie, Chart.VerticalBar.Grouped, Chart.VerticalBar, Chart.HorizontalBar, Chart.HorizontalBar.Stacked, Chart.Line, Chart.Gauge, CodeBlock, drop
grid.area		String	The area of a Layout.AreaGrid layout in which an element must be displayed.
height		String	Controls the height of the element. When set to stretch, the element uses the remaining vertical space in its container. Allowed values: auto, stretch Default value: auto
horizontalAlignment		String	Controls how the element must be horizontally aligned. Allowed values: Left, Center, Right
id		String	A unique identifier for the input element or action.
isVisible		Boolean	Controls if the element is visible. Default value: true
lang		String	The locale associated with the input element.
requires		Object	A list of capabilities the element requires the host application to support. If the host application doesn't support at least one of the listed capabilities, the element isn't rendered or its fallback is rendered, if provided. Supported value: HostCapabilities
separator		Boolean	Controls whether a separator line must be displayed above the element to visually separate it from the previous element. No separator is displayed for the first element in a container, even if this property is set to true. Default value: false
spacing		String	Controls the amount of space between this element and the previous one. No space is added for the first element in a container. Allowed values: None, Small, Default, Medium, Large, ExtraLarge, Padding Default value: Default
targetWidth		String	Controls the card width for which the element must be displayed. If targetWidth isn't specified, the element is rendered at all card widths. Using targetWidth makes it possible to author responsive cards that adapt their layout to the available horizontal space. For more information, see Adaptive Card responsive layout. Allowed values: VeryNarrow, Narrow, Standard, Wide, atLeast:VeryNarrow, atMost:VeryNarrow, atLeast:Narrow, atMost:Narrow, atLeast:Standard, atMost:Standard, atLeast:Wide, atMost:Wide
title		String	The title of the chart.

Here are the properties of the data array:

Property	Required	Type	Description
color		String	The color to use for the data point. Allowed values: good, warning, attention, neutral, categoricalRed, categoricalPurple, categoricalLavender, categoricalBlue, categoricalLightBlue, categoricalTeal, categoricalGreen, categoricalLime, categoricalMarigold, sequential1, sequential2, sequential3, sequential4, sequential5, sequential6, sequential7, sequential8, divergingBlue, divergingLightBlue, divergingCyan, divergingTeal, divergingYellow, divergingPeach, divergingLightRed, divergingRed, divergingMaroon, divergingGray
legend		String	The legend of the chart.
value		Number	The value associated with the data point.

Stacked horizontal bar chart

You can use the Chart.HorizontalBar.Stacked element to add a stacked horizontal bar chart in an Adaptive Card.

Card

Payload

{
  "type": "AdaptiveCard",
  "version": "1.5",
  "body": [
    {
      "type": "Chart.HorizontalBar.Stacked",
      "title": "Sample",
      "data": [
        {
          "title": "Outlook",
          "data": [
            {
              "legend": "2023-05-01",
              "value": 24,
              "color": "good"
            },
            {
              "legend": "2023-05-02",
              "value": 27,
              "color": "warning"
            },
            {
              "legend": "2023-05-03",
              "value": 18,
              "color": "attention"
            }
          ]
        },
        {
          "title": "Teams",
          "data": [
            {
              "legend": "2023-05-01",
              "value": 9,
              "color": "good"
            },
            {
              "legend": "2023-05-02",
              "value": 100,
              "color": "warning"
            },
            {
              "legend": "2023-05-03",
              "value": 22,
              "color": "attention"
            }
          ]
        }
      ]
    }
  ]
}

Here are the properties of the Chart.HorizontalBar.Stacked element:

Property	Required	Type	Description
type	✔️	String	Must be Chart.HorizontalBar.Stacked.
color		String	The color to use for all data points. Allowed values: good, warning, attention, neutral, categoricalRed, categoricalPurple, categoricalLavender, categoricalBlue, categoricalLightBlue, categoricalTeal, categoricalGreen, categoricalLime, categoricalMarigold, sequential1, sequential2, sequential3, sequential4, sequential5, sequential6, sequential7, sequential8, divergingBlue, divergingLightBlue, divergingCyan, divergingTeal, divergingYellow, divergingPeach, divergingLightRed, divergingRed, divergingMaroon, divergingGray
colorSet		String	The name of the set of colors to use to render the chart.
data		Array of objects	The data points in the chart.
fallback		Object or String	An alternate element to render if this element is unsupported or if the host application doesn't support all the capabilities specified in the requires property. Allowed values: Container, ActionSet, ColumnSet, Media, RichTextBlock, Table, TextBlock, FactSet, ImageSet, Image, Input.Text, Input.Date, Input.Time, Input.Number, Input.Toggle, Input.ChoiceSet, Input.Rating, Rating, CompoundButton, Icon, Chart.Donut, Chart.Pie, Chart.VerticalBar.Grouped, Chart.VerticalBar, Chart.HorizontalBar, Chart.HorizontalBar.Stacked, Chart.Line, Chart.Gauge, CodeBlock, drop
grid.area		String	The area of a Layout.AreaGrid layout in which an element must be displayed.
height		String	Controls the height of the element. When set to stretch, the element uses the remaining vertical space in its container. Allowed values: auto, stretch Default value: auto
horizontalAlignment		String	Controls how the element must be horizontally aligned. Allowed values: Left, Center, Right
id		String	A unique identifier for the input element or action.
isVisible		Boolean	Controls if the element is visible. Default value: true
lang		String	The locale associated with the input element.
requires		Object	A list of capabilities the element requires the host application to support. If the host application doesn't support at least one of the listed capabilities, the element isn't rendered or its fallback is rendered, if provided. Supported value: HostCapabilities
separator		Boolean	Controls whether a separator line must be displayed above the element to visually separate it from the previous element. No separator is displayed for the first element in a container, even if this property is set to true. Default value: false
spacing		String	Controls the amount of space between this element and the previous one. No space is added for the first element in a container. Allowed values: None, Small, Default, Medium, Large, ExtraLarge, Padding Default value: Default
targetWidth		String	Controls the card width for which the element must be displayed. If targetWidth isn't specified, the element is rendered at all card widths. Using targetWidth makes it possible to author responsive cards that adapt their layout to the available horizontal space. For more information, see Adaptive Card responsive layout. Allowed values: VeryNarrow, Narrow, Standard, Wide, atLeast:VeryNarrow, atMost:VeryNarrow, atLeast:Narrow, atMost:Narrow, atLeast:Standard, atMost:Standard, atLeast:Wide, atMost:Wide
title		String	The title of the chart.
xAxisTitle		String	The title of the x axis.
yAxisTitle		String	The title of the y axis.

Here are the properties of the data array:

Property	Required	Type	Description
data		Array of objects	The data points in the series.
title		String	The title of the series.

Here are the properties of the nested data array:

Property	Required	Type	Description
color		String	The color to use for the data point. Allowed values: good, warning, attention, neutral, categoricalRed, categoricalPurple, categoricalLavender, categoricalBlue, categoricalLightBlue, categoricalTeal, categoricalGreen, categoricalLime, categoricalMarigold, sequential1, sequential2, sequential3, sequential4, sequential5, sequential6, sequential7, sequential8, divergingBlue, divergingLightBlue, divergingCyan, divergingTeal, divergingYellow, divergingPeach, divergingLightRed, divergingRed, divergingMaroon, divergingGray
legend		String	The legend associated with the data point.
value		Number	The value of the data point.

Vertical bar chart

You can use the Chart.VerticalBar element to add a vertical bar chart in an Adaptive Card.

Card

Payload

{
  "type": "AdaptiveCard",
  "version": "1.5",
  "body": [
    {
      "type": "Chart.VerticalBar",
      "title": "Sample",
      "xAxisTitle": "Days",
      "yAxisTitle": "Sales",
      "colorSet": "categorical",
      "data": [
        {
          "x": "Pear",
          "y": 59
        },
        {
          "x": "Banana",
          "y": 292
        },
        {
          "x": "Apple",
          "y": 143
        },
        {
          "x": "Peach",
          "y": 98
        },
        {
          "x": "Kiwi",
          "y": 179
        },
        {
          "x": "Grapefruit",
          "y": 20
        },
        {
          "x": "Orange",
          "y": 212
        },
        {
          "x": "Cantaloupe",
          "y": 68
        },
        {
          "x": "Grape",
          "y": 102
        },
        {
          "x": "Tangerine",
          "y": 38
        }
      ]
    }
  ]
}

Here are the properties of the Chart.VerticalBar element:

Property	Required	Type	Description
type	✔️	String	Must be Chart.VerticalBar.
color		String	The color to use for all data points. Allowed values: good, warning, attention, neutral, categoricalRed, categoricalPurple, categoricalLavender, categoricalBlue, categoricalLightBlue, categoricalTeal, categoricalGreen, categoricalLime, categoricalMarigold, sequential1, sequential2, sequential3, sequential4, sequential5, sequential6, sequential7, sequential8, divergingBlue, divergingLightBlue, divergingCyan, divergingTeal, divergingYellow, divergingPeach, divergingLightRed, divergingRed, divergingMaroon, divergingGray
colorSet		String	The name of the set of colors to use to render the chart.
data		Array of objects	The data points in the chart.
fallback		Object or String	An alternate element to render if this element is unsupported or if the host application doesn't support all the capabilities specified in the requires property. Allowed values: Container, ActionSet, ColumnSet, Media, RichTextBlock, Table, TextBlock, FactSet, ImageSet, Image, Input.Text, Input.Date, Input.Time, Input.Number, Input.Toggle, Input.ChoiceSet, Input.Rating, Rating, CompoundButton, Icon, Chart.Donut, Chart.Pie, Chart.VerticalBar.Grouped, Chart.VerticalBar, Chart.HorizontalBar, Chart.HorizontalBar.Stacked, Chart.Line, Chart.Gauge, CodeBlock, drop
grid.area		String	The area of a Layout.AreaGrid layout in which an element must be displayed.
height		String	Controls the height of the element. When set to stretch, the element uses the remaining vertical space in its container. Allowed values: auto, stretch Default value: auto
horizontalAlignment		String	Controls how the element must be horizontally aligned. Allowed values: Left, Center, Right
id		String	A unique identifier for the input element or action.
isVisible		Boolean	Controls if the element is visible. Default value: true
lang		String	The locale associated with the input element.
requires		Object	A list of capabilities the element requires the host application to support. If the host application doesn't support at least one of the listed capabilities, the element isn't rendered or its fallback is rendered, if provided. Supported value: HostCapabilities
separator		Boolean	Controls whether a separator line must be displayed above the element to visually separate it from the previous element. No separator is displayed for the first element in a container, even if this property is set to true. Default value: false
showBarValues		Boolean	Controls if the bar values must be displayed. Default value: false
spacing		String	Controls the amount of space between this element and the previous one. No space is added for the first element in a container. Allowed values: None, Small, Default, Medium, Large, ExtraLarge, Padding Default value: Default
targetWidth		String	Controls the card width for which the element must be displayed. If targetWidth isn't specified, the element is rendered at all card widths. Using targetWidth makes it possible to author responsive cards that adapt their layout to the available horizontal space. For more information, see Adaptive Card responsive layout. Allowed values: VeryNarrow, Narrow, Standard, Wide, atLeast:VeryNarrow, atMost:VeryNarrow, atLeast:Narrow, atMost:Narrow, atLeast:Standard, atMost:Standard, atLeast:Wide, atMost:Wide
title		String	The title of the chart.
xAxisTitle		String	The title of the x axis.
yAxisTitle		String	The title of the y axis.

Here are the properties of the data array:

Property	Required	Type	Description
color		String	The color to use for the data point. Allowed values: good, warning, attention, neutral, categoricalRed, categoricalPurple, categoricalLavender, categoricalBlue, categoricalLightBlue, categoricalTeal, categoricalGreen, categoricalLime, categoricalMarigold, sequential1, sequential2, sequential3, sequential4, sequential5, sequential6, sequential7, sequential8, divergingBlue, divergingLightBlue, divergingCyan, divergingTeal, divergingYellow, divergingPeach, divergingLightRed, divergingRed, divergingMaroon, divergingGray
x		One of number or string	The x axis value of the data point.
y		Number	The y axis value of the data point.

Code sample

Name	Description	.Node.js	.NET
Cards Formatting	This sample app demonstrates the various charts in Adaptive Cards.	View	View

See also

• Cards and dialogs
• Adaptive Card responsive layout
