Практическое руководство. Закрепление дочерних элементов управления в элементе управления FlowLayoutPanel

  • Статья

Элемент управления FlowLayoutPanel поддерживает следующие свойства в своих дочерних элементах управления: Anchor и Dock.

Закрепление дочерних элементов управления в элементе управления FlowLayoutPanel

  1. Создайте элемент управления FlowLayoutPanel в форме.

  2. Присвойте свойству Width элемента управления FlowLayoutPanel значение 300, а свойству FlowDirection — значение TopDown.

  3. Создайте два элемента управления Button и поместите их в элементе управления FlowLayoutPanel.

  4. Присвойте свойству Width первой кнопки значение 200.

  5. Свойству Dock второй кнопки присвойте значение Fill.

    Примечание

    Вторая кнопка принимает ту же ширину, что и первая кнопка.Она не растягивается по ширине элемента управления FlowLayoutPanel.

  6. Свойству Dock второй кнопки присвойте значение None. Это позволит кнопке принять исходную ширину.

  7. Свойству Anchor второй кнопки присвойте значение Left, Right.

    Важно!

    Вторая кнопка принимает ту же ширину, что и первая кнопка.Она не растягивается по ширине элемента управления FlowLayoutPanel.Общее правило закрепления в элементе управления FlowLayoutPanel заключается в следующем: в вертикальном направлении элемент управления FlowLayoutPanel рассчитывает ширину предполагаемого столбца исходя из самого широкого элемента управления в столбце.Все остальные элементы в этом столбце со свойствами Anchor или Dock выравниваются или растягиваются до размера предполагаемого столбца.В горизонтальном направлении происходит примерно то же самое.Элемент управления FlowLayoutPanel вычисляет высоту предполагаемой строки на основе самого высокого дочернего элемента управления в строке, и все закрепленные дочерние элементы управления в этой строке выравниваются или изменяются в размере в соответствии с предполагаемой строкой.

Пример

На следующем рисунке показаны четыре кнопки, прикрепленные по отношению к синей кнопке в FlowLayoutPanel. Свойство FlowDirection имеет значение LeftToRight.

Закрепление FlowLayoutPanel

На следующем рисунке показаны четыре кнопки, прикрепленные по отношению к синей кнопке в FlowLayoutPanel. Свойство FlowDirection имеет значение TopDown.

Закрепление FlowLayoutPanel

В следующем примере кода демонстрируются различные значения свойства Anchor для элемента управления Button в элементе управления FlowLayoutPanel.

Imports System
Imports System.Collections.Generic
Imports System.ComponentModel
Imports System.Drawing
Imports System.Windows.Forms




Public Class Form1
   Inherits Form

   Public Sub New()
      InitializeComponent()
   End Sub 'New
   Private flowLayoutPanel3 As FlowLayoutPanel
   Private label2 As Label
   Private button11 As Button
   Private button12 As Button
   Private button13 As Button
   Private button14 As Button
   Private button15 As Button
   Private flowLayoutPanel1 As FlowLayoutPanel
   Private label1 As Label
   Private button1 As Button
   Private button2 As Button
   Private button3 As Button
   Private button4 As Button
   Private button5 As Button

   Private components As System.ComponentModel.IContainer = Nothing


   Protected Overrides Sub Dispose(disposing As Boolean)
      If disposing AndAlso (components IsNot Nothing) Then
         components.Dispose()
      End If
      MyBase.Dispose(disposing)
   End Sub 'Dispose


   Private Sub InitializeComponent()
      Me.flowLayoutPanel3 = New System.Windows.Forms.FlowLayoutPanel()
      Me.label2 = New System.Windows.Forms.Label()
      Me.button11 = New System.Windows.Forms.Button()
      Me.button12 = New System.Windows.Forms.Button()
      Me.button13 = New System.Windows.Forms.Button()
      Me.button14 = New System.Windows.Forms.Button()
      Me.button15 = New System.Windows.Forms.Button()
      Me.flowLayoutPanel1 = New System.Windows.Forms.FlowLayoutPanel()
      Me.label1 = New System.Windows.Forms.Label()
      Me.button1 = New System.Windows.Forms.Button()
      Me.button2 = New System.Windows.Forms.Button()
      Me.button3 = New System.Windows.Forms.Button()
      Me.button4 = New System.Windows.Forms.Button()
      Me.button5 = New System.Windows.Forms.Button()
      Me.flowLayoutPanel3.SuspendLayout()
      Me.flowLayoutPanel1.SuspendLayout()
      Me.SuspendLayout()
      '
      ' flowLayoutPanel3
      '
      Me.flowLayoutPanel3.Anchor = CType(System.Windows.Forms.AnchorStyles.Top Or System.Windows.Forms.AnchorStyles.Bottom Or System.Windows.Forms.AnchorStyles.Left Or System.Windows.Forms.AnchorStyles.Right, System.Windows.Forms.AnchorStyles)
      Me.flowLayoutPanel3.BorderStyle = System.Windows.Forms.BorderStyle.FixedSingle
      Me.flowLayoutPanel3.Controls.Add(Me.label2)
      Me.flowLayoutPanel3.Controls.Add(Me.button11)
      Me.flowLayoutPanel3.Controls.Add(Me.button12)
      Me.flowLayoutPanel3.Controls.Add(Me.button13)
      Me.flowLayoutPanel3.Controls.Add(Me.button14)
      Me.flowLayoutPanel3.Controls.Add(Me.button15)
      Me.flowLayoutPanel3.Location = New System.Drawing.Point(12, 12)
      Me.flowLayoutPanel3.Name = "flowLayoutPanel3"
      Me.flowLayoutPanel3.Size = New System.Drawing.Size(631, 100)
      Me.flowLayoutPanel3.TabIndex = 2
      '
      ' label2
      '
      Me.label2.Anchor = System.Windows.Forms.AnchorStyles.None
      Me.label2.AutoSize = True
      Me.label2.Location = New System.Drawing.Point(3, 28)
      Me.label2.Name = "label2"
      Me.label2.Size = New System.Drawing.Size(138, 14)
      Me.label2.TabIndex = 10
      Me.label2.Text = "FlowDirection=LeftToRight"
      '
      ' button11
      '
      Me.button11.Anchor = System.Windows.Forms.AnchorStyles.Bottom
      Me.button11.AutoSize = True
      Me.button11.Location = New System.Drawing.Point(147, 44)
      Me.button11.Name = "button11"
      Me.button11.Size = New System.Drawing.Size(86, 23)
      Me.button11.TabIndex = 5
      Me.button11.Text = "Anchor=Bottom"
      '
      ' button12
      '
      Me.button12.Anchor = CType(System.Windows.Forms.AnchorStyles.Top Or System.Windows.Forms.AnchorStyles.Bottom, System.Windows.Forms.AnchorStyles)
      Me.button12.AutoSize = True
      Me.button12.Location = New System.Drawing.Point(239, 3)
      Me.button12.Name = "button12"
      Me.button12.Size = New System.Drawing.Size(111, 64)
      Me.button12.TabIndex = 6
      Me.button12.Text = "Anchor=Top, Bottom"
      '
      ' button13
      '
      Me.button13.Anchor = System.Windows.Forms.AnchorStyles.None
      Me.button13.BackColor = System.Drawing.SystemColors.GradientActiveCaption
      Me.button13.Location = New System.Drawing.Point(356, 3)
      Me.button13.Name = "button13"
      Me.button13.Size = New System.Drawing.Size(75, 64)
      Me.button13.TabIndex = 7
      '
      ' button14
      '
      Me.button14.Dock = System.Windows.Forms.DockStyle.Bottom
      Me.button14.Location = New System.Drawing.Point(437, 44)
      Me.button14.Name = "button14"
      Me.button14.TabIndex = 8
      Me.button14.Text = "Dock=Bottom"
      '
      ' button15
      '
      Me.button15.Dock = System.Windows.Forms.DockStyle.Fill
      Me.button15.Location = New System.Drawing.Point(518, 3)
      Me.button15.Name = "button15"
      Me.button15.Size = New System.Drawing.Size(75, 64)
      Me.button15.TabIndex = 9
      Me.button15.Text = "Dock=Fill"
      '
      ' flowLayoutPanel1
      '
      Me.flowLayoutPanel1.Anchor = CType(System.Windows.Forms.AnchorStyles.Bottom Or System.Windows.Forms.AnchorStyles.Left Or System.Windows.Forms.AnchorStyles.Right, System.Windows.Forms.AnchorStyles)
      Me.flowLayoutPanel1.BorderStyle = System.Windows.Forms.BorderStyle.FixedSingle
      Me.flowLayoutPanel1.Controls.Add(Me.label1)
      Me.flowLayoutPanel1.Controls.Add(Me.button1)
      Me.flowLayoutPanel1.Controls.Add(Me.button2)
      Me.flowLayoutPanel1.Controls.Add(Me.button3)
      Me.flowLayoutPanel1.Controls.Add(Me.button4)
      Me.flowLayoutPanel1.Controls.Add(Me.button5)
      Me.flowLayoutPanel1.FlowDirection = System.Windows.Forms.FlowDirection.TopDown
      Me.flowLayoutPanel1.Location = New System.Drawing.Point(12, 118)
      Me.flowLayoutPanel1.Name = "flowLayoutPanel1"
      Me.flowLayoutPanel1.Size = New System.Drawing.Size(200, 209)
      Me.flowLayoutPanel1.TabIndex = 3
      '
      ' label1
      '
      Me.label1.AutoSize = True
      Me.label1.Location = New System.Drawing.Point(3, 3)
      Me.label1.Name = "label1"
      Me.label1.Size = New System.Drawing.Size(128, 14)
      Me.label1.TabIndex = 11
      Me.label1.Text = "FlowDirection=TopDown"
      '
      ' button1
      '
      Me.button1.Anchor = System.Windows.Forms.AnchorStyles.Right
      Me.button1.Location = New System.Drawing.Point(74, 23)
      Me.button1.Name = "button1"
      Me.button1.TabIndex = 5
      Me.button1.Text = "Anchor=Right"
      '
      ' button2
      '
      Me.button2.Anchor = CType(System.Windows.Forms.AnchorStyles.Left Or System.Windows.Forms.AnchorStyles.Right, System.Windows.Forms.AnchorStyles)
      Me.button2.Location = New System.Drawing.Point(3, 52)
      Me.button2.Name = "button2"
      Me.button2.Size = New System.Drawing.Size(146, 23)
      Me.button2.TabIndex = 6
      Me.button2.Text = "Anchor=Left, Right"
      '
      ' button3
      '
      Me.button3.BackColor = System.Drawing.SystemColors.GradientActiveCaption
      Me.button3.Location = New System.Drawing.Point(3, 81)
      Me.button3.Name = "button3"
      Me.button3.Size = New System.Drawing.Size(146, 23)
      Me.button3.TabIndex = 7
      '
      ' button4
      '
      Me.button4.Dock = System.Windows.Forms.DockStyle.Right
      Me.button4.Location = New System.Drawing.Point(74, 110)
      Me.button4.Name = "button4"
      Me.button4.TabIndex = 8
      Me.button4.Text = "Dock=Right"
      '
      ' button5
      '
      Me.button5.Dock = System.Windows.Forms.DockStyle.Fill
      Me.button5.Location = New System.Drawing.Point(3, 139)
      Me.button5.Name = "button5"
      Me.button5.Size = New System.Drawing.Size(146, 23)
      Me.button5.TabIndex = 9
      Me.button5.Text = "Dock=Fill"
      '
      ' Form1
      '
      Me.ClientSize = New System.Drawing.Size(658, 341)
      Me.Controls.Add(flowLayoutPanel1)
      Me.Controls.Add(flowLayoutPanel3)
      Me.Name = "Form1"
      Me.Text = "Form1"
      Me.flowLayoutPanel3.ResumeLayout(False)
      Me.flowLayoutPanel3.PerformLayout()
      Me.flowLayoutPanel1.ResumeLayout(False)
      Me.flowLayoutPanel1.PerformLayout()
      Me.ResumeLayout(False)
   End Sub 'InitializeComponent


   <STAThread()>  _
   Shared Sub Main()
      Application.EnableVisualStyles()
      Application.Run(New Form1())
   End Sub 'Main
End Class 'Form1

using System;
using System.Collections.Generic;
using System.ComponentModel;
using System.Data;
using System.Drawing;
using System.Windows.Forms;


public class Form1 : Form
{
    public Form1()
    {
        InitializeComponent();
    }
    private FlowLayoutPanel flowLayoutPanel3;
    private Label label2;
    private Button button11;
    private Button button12;
    private Button button13;
    private Button button14;
    private Button button15;
    private FlowLayoutPanel flowLayoutPanel1;
    private Label label1;
    private Button button1;
    private Button button2;
    private Button button3;
    private Button button4;
    private Button button5;

    private System.ComponentModel.IContainer components = null;

    protected override void Dispose(bool disposing)
    {
        if (disposing && (components != null))
        {
            components.Dispose();
        }
        base.Dispose(disposing);
    }

    private void InitializeComponent()
    {
        this.flowLayoutPanel3 = new System.Windows.Forms.FlowLayoutPanel();
        this.label2 = new System.Windows.Forms.Label();
        this.button11 = new System.Windows.Forms.Button();
        this.button12 = new System.Windows.Forms.Button();
        this.button13 = new System.Windows.Forms.Button();
        this.button14 = new System.Windows.Forms.Button();
        this.button15 = new System.Windows.Forms.Button();
        this.flowLayoutPanel1 = new System.Windows.Forms.FlowLayoutPanel();
        this.label1 = new System.Windows.Forms.Label();
        this.button1 = new System.Windows.Forms.Button();
        this.button2 = new System.Windows.Forms.Button();
        this.button3 = new System.Windows.Forms.Button();
        this.button4 = new System.Windows.Forms.Button();
        this.button5 = new System.Windows.Forms.Button();
        this.flowLayoutPanel3.SuspendLayout();
        this.flowLayoutPanel1.SuspendLayout();
        this.SuspendLayout();
        //
        // flowLayoutPanel3
        //
        this.flowLayoutPanel3.Anchor = ((System.Windows.Forms.AnchorStyles)((((System.Windows.Forms.AnchorStyles.Top | System.Windows.Forms.AnchorStyles.Bottom)
                    | System.Windows.Forms.AnchorStyles.Left)
                    | System.Windows.Forms.AnchorStyles.Right)));
        this.flowLayoutPanel3.BorderStyle = System.Windows.Forms.BorderStyle.FixedSingle;
        this.flowLayoutPanel3.Controls.Add(this.label2);
        this.flowLayoutPanel3.Controls.Add(this.button11);
        this.flowLayoutPanel3.Controls.Add(this.button12);
        this.flowLayoutPanel3.Controls.Add(this.button13);
        this.flowLayoutPanel3.Controls.Add(this.button14);
        this.flowLayoutPanel3.Controls.Add(this.button15);
        this.flowLayoutPanel3.Location = new System.Drawing.Point(12, 12);
        this.flowLayoutPanel3.Name = "flowLayoutPanel3";
        this.flowLayoutPanel3.Size = new System.Drawing.Size(631, 100);
        this.flowLayoutPanel3.TabIndex = 2;
        //
        // label2
        //
        this.label2.Anchor = System.Windows.Forms.AnchorStyles.None;
        this.label2.AutoSize = true;
        this.label2.Location = new System.Drawing.Point(3, 28);
        this.label2.Name = "label2";
        this.label2.Size = new System.Drawing.Size(138, 14);
        this.label2.TabIndex = 10;
        this.label2.Text = "FlowDirection=LeftToRight";
        //
        // button11
        //
        this.button11.Anchor = System.Windows.Forms.AnchorStyles.Bottom;
        this.button11.AutoSize = true;
        this.button11.Location = new System.Drawing.Point(147, 44);
        this.button11.Name = "button11";
        this.button11.Size = new System.Drawing.Size(86, 23);
        this.button11.TabIndex = 5;
        this.button11.Text = "Anchor=Bottom";
        //
        // button12
        //
        this.button12.Anchor = ((System.Windows.Forms.AnchorStyles)((System.Windows.Forms.AnchorStyles.Top | System.Windows.Forms.AnchorStyles.Bottom)));
        this.button12.AutoSize = true;
        this.button12.Location = new System.Drawing.Point(239, 3);
        this.button12.Name = "button12";
        this.button12.Size = new System.Drawing.Size(111, 64);
        this.button12.TabIndex = 6;
        this.button12.Text = "Anchor=Top, Bottom";
        //
        // button13
        //
        this.button13.Anchor = System.Windows.Forms.AnchorStyles.None;
        this.button13.BackColor = System.Drawing.SystemColors.GradientActiveCaption;
        this.button13.Location = new System.Drawing.Point(356, 3);
        this.button13.Name = "button13";
        this.button13.Size = new System.Drawing.Size(75, 64);
        this.button13.TabIndex = 7;
        //
        // button14
        //
        this.button14.Dock = System.Windows.Forms.DockStyle.Bottom;
        this.button14.Location = new System.Drawing.Point(437, 44);
        this.button14.Name = "button14";
        this.button14.TabIndex = 8;
        this.button14.Text = "Dock=Bottom";
        //
        // button15
        //
        this.button15.Dock = System.Windows.Forms.DockStyle.Fill;
        this.button15.Location = new System.Drawing.Point(518, 3);
        this.button15.Name = "button15";
        this.button15.Size = new System.Drawing.Size(75, 64);
        this.button15.TabIndex = 9;
        this.button15.Text = "Dock=Fill";
        //
        // flowLayoutPanel1
        //
        this.flowLayoutPanel1.Anchor = ((System.Windows.Forms.AnchorStyles)(((System.Windows.Forms.AnchorStyles.Bottom | System.Windows.Forms.AnchorStyles.Left)
                    | System.Windows.Forms.AnchorStyles.Right)));
        this.flowLayoutPanel1.BorderStyle = System.Windows.Forms.BorderStyle.FixedSingle;
        this.flowLayoutPanel1.Controls.Add(this.label1);
        this.flowLayoutPanel1.Controls.Add(this.button1);
        this.flowLayoutPanel1.Controls.Add(this.button2);
        this.flowLayoutPanel1.Controls.Add(this.button3);
        this.flowLayoutPanel1.Controls.Add(this.button4);
        this.flowLayoutPanel1.Controls.Add(this.button5);
        this.flowLayoutPanel1.FlowDirection = System.Windows.Forms.FlowDirection.TopDown;
        this.flowLayoutPanel1.Location = new System.Drawing.Point(12, 118);
        this.flowLayoutPanel1.Name = "flowLayoutPanel1";
        this.flowLayoutPanel1.Size = new System.Drawing.Size(200, 209);
        this.flowLayoutPanel1.TabIndex = 3;
        //
        // label1
        //
        this.label1.AutoSize = true;
        this.label1.Location = new System.Drawing.Point(3, 3);
        this.label1.Name = "label1";
        this.label1.Size = new System.Drawing.Size(128, 14);
        this.label1.TabIndex = 11;
        this.label1.Text = "FlowDirection=TopDown";
        //
        // button1
        //
        this.button1.Anchor = System.Windows.Forms.AnchorStyles.Right;
        this.button1.Location = new System.Drawing.Point(74, 23);
        this.button1.Name = "button1";
        this.button1.TabIndex = 5;
        this.button1.Text = "Anchor=Right";
        //
        // button2
        //
        this.button2.Anchor = ((System.Windows.Forms.AnchorStyles)((System.Windows.Forms.AnchorStyles.Left | System.Windows.Forms.AnchorStyles.Right)));
        this.button2.Location = new System.Drawing.Point(3, 52);
        this.button2.Name = "button2";
        this.button2.Size = new System.Drawing.Size(146, 23);
        this.button2.TabIndex = 6;
        this.button2.Text = "Anchor=Left, Right";
        //
        // button3
        //
        this.button3.BackColor = System.Drawing.SystemColors.GradientActiveCaption;
        this.button3.Location = new System.Drawing.Point(3, 81);
        this.button3.Name = "button3";
        this.button3.Size = new System.Drawing.Size(146, 23);
        this.button3.TabIndex = 7;
        //
        // button4
        //
        this.button4.Dock = System.Windows.Forms.DockStyle.Right;
        this.button4.Location = new System.Drawing.Point(74, 110);
        this.button4.Name = "button4";
        this.button4.TabIndex = 8;
        this.button4.Text = "Dock=Right";
        //
        // button5
        //
        this.button5.Dock = System.Windows.Forms.DockStyle.Fill;
        this.button5.Location = new System.Drawing.Point(3, 139);
        this.button5.Name = "button5";
        this.button5.Size = new System.Drawing.Size(146, 23);
        this.button5.TabIndex = 9;
        this.button5.Text = "Dock=Fill";
        //
        // Form1
        //
        this.ClientSize = new System.Drawing.Size(658, 341);
        this.Controls.Add(this.flowLayoutPanel1);
        this.Controls.Add(this.flowLayoutPanel3);
        this.Name = "Form1";
        this.Text = "Form1";
        this.flowLayoutPanel3.ResumeLayout(false);
        this.flowLayoutPanel3.PerformLayout();
        this.flowLayoutPanel1.ResumeLayout(false);
        this.flowLayoutPanel1.PerformLayout();
        this.ResumeLayout(false);

    }

    [STAThread]
    static void Main()
    {
        Application.EnableVisualStyles();
        Application.Run(new Form1());
    }
}

Компиляция кода

Для этого примера необходимо следующее:

  • Ссылки на сборки System, System.Data, System.Drawing и System.Windows.Forms.

Дополнительные сведения о построении этого примера из командной строки для Visual Basic или Visual C# см. в разделе Построение из командной строки (Visual Basic) или Построение из командной строки с помощью csc.exe. Можно также построить этот пример в Visual Studio путем вставки кода в новый проект. Дополнительные сведения см. в следующем разделе. Практическое руководство. Компиляция и выполнение откомпилированного примера кода формы Windows Forms с помощью Visual Studio и Практическое руководство. Компиляция и выполнение откомпилированного примера кода формы Windows Forms с помощью Visual Studio и Практическое руководство. Компиляция и выполнение откомпилированного примера кода формы Windows Forms с помощью Visual Studio.

См. также

Ссылки

FlowLayoutPanel

Общие сведения об элементе управления FlowLayoutPanel
